Hardware: H3MB18/N2MB02/N3MB01

Video/Audio Input
IP Video Input: PoE IP Camera x 8
Audio Input: Cameras with built-in mic

Video/Audio Output
HDMI Output Resolution: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
VGA Output Resolution: 1920x1080, 1280x1024, 1280x720, 1024x768
Audio output: 1-Channel, RCA

Decoding
Video Format: H.264, H.265
Live View / Playback Resolution: 4096x3072, 3840x2160, 2560x1920, 2560x1440, 2048x1536, 2304x1296, 1080p, 720p
Synchronous Playback: Up to 4 channels

HDD
SATA: 1 x SATA interface (1 x 2TB HDD included)
External HDD: 1 eSATA Interface for HDD
Capacity: Up to 12TB (max. 6TB capacity for each HDD)

External Interface
USB Interface: 2 x USB 2.0
Network Interface: 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface for LAN/WAN; 8, RJ-45 10/100 Mbps self-adaptive PoE Ethernet interface for IP camera

PoE
Max. Power Per Port: 25W
Supported Standard: IEEE 802.3af/at

Network
Network Protocols: HTTP, TCP/IP, UDP, DHCP, P2P, UPNP, RTSP, SMTP, SSL/TLS, DNS,
DDNS, NTP, FTP
Browsers Supported: Edge, Firefox, Chrome, Safari
OS Supported: PC: Windows, Mac OS; smartphone: iOS, Android
Max. User Access: 20 users (1 admin account & 19 user accounts); supports up to 12 simultaneous
video streams (10 substreams & 2 mainstreams)

General
Power Supply: DC 48V~53V
Power Consumption: <10W (Without HDD&PoE)
Working Environment Temperature: -10°C~+45°C (14°F~113°F); humidity: 10%~90%
Dimensions: 260 x 41 x 230mm
Weight: 1.4kg
