SOLARNI REGULATOR EPSOLAR XTRA2206N-XDS2 MPPT

Koda: 06SK-XTRA2206N-XDS2

20A solarni regulator napetosti za vzpostavitev sončne elektrarne,...

dostava v 24h
zaloga: 2

Opis izdelka

- Advanced MPPT technology & ultra-fast tracking speed is up to 99.5 % guaranteed
- Maximum DC/DC transfer e ciency is as high as 98 %,full load transfer e ciency is up to 97.4 %
- Wide MPP operating voltage range
- Low temperature protection and self activate function for lithium battery charging
- Limit charging power & current over rated range
 Real-time energy statistics function
- Multiple load work modes
- Comprehensive electronic protection
- Compatible with lead acid and lithium-ion batteries
- Over temperature protection and power degrading in higher temperature
- Optional LCD display units (XDB1/XDS1/XDS2) and accessories
- High quality and low failure rate components of ST or IR to ensure service life
- Isolated RS485 communication port with 5V/200mA protected output, with standard Modbus protocol
- Monitor and set the parameters via APP or PC software
- Dustproof and waterproof design with IP32 protection class
- CE certification (LVD IEC62109,EMC EN3/1-6-61000

Technical specifications
- Nominal system voltage: 12/24VDC Auto
- Rated charge current: 20A
- Rated discharge current: 20A
- Battery input voltage range: 8V~32V
- Max. PV open circuit voltage: 46V~60V
- MPPT Voltage Range: (Battery voltage +2V)~36V
- Max. PV Input Power (W/V): 260/12; 520/24
- Equalization Voltage: Sealed: 14.6V; Flooded: 14.8V; User: 17~9V
- Boost Voltage: Gel:14.2V; Sealed:14.4V; Flooded:14.6V; User: 17-9 V
- Float Voltage: Gel /Sealed /Flooded: 13.8V; User: 17~9V
- Low Voltage Reconnect Voltage: Gel /Sealed /Flooded: 12.6V; User: 17~9V
- Low Voltage Disconnect Voltage: Gel /Sealed /Flooded: 11.1V; User: 17~9V
- Self-consumption: 12V≤14mA; 24V≤15mA
- Discharge Circuit Voltage Drop: ≤0.23V
- Temperature compensation coefficient: -3mV/°C/2V
- Working environment temperature: -25°C~+50°C
- Humidity: ≤95%,(N.C.)
- Enclosure: IP33
- Grounding: Common negative grounding
- Overall dimension: 217×158×56.5mm
- Mounting dimension: 160×149mm
- Mounting hole size: Φ5
- Terminals mm²: 6AWG/16
- Recommended cable: 10AWG(6mm2)
- Net weight: 0.96 kg
